Living
/ Dining / Bedrooms : Wood Flooring
Kitchen
(Enclosed Type) :
Ceramic Tiles
(Open Type) :
Wood Flooring
Utility / Maid's Room : Colored cement finish
Toilet & Bath :
Ceramic Tiles |
Function
Room
Floor: Ceramic Tiles
Wall: Painted Plastic plaster
Ceiling: Painted Gypsum Board |
CEILING
FINISH
Living / Dining concrete : Painted rubbed
: painted gypsum board
Bedroom concrete :
Painted rubbed
Kitchen Area concrete : Painted rubbed
Utility / Maid's Room concrete : Painted rubbed
: painted gypsum board
Toilet & Bath : Painted gypsum board |
WALL
FINISH
Living / Dining plaster : Painted cement
Bedroom plaster
: Painted cement
Kitchen plaster
: Painted cement
Utility Room
: Painted cement
Maid's Room plaster : Painted cement |
AIR
CONDITIONING
- Provision for window type unit
- WACU opening with temporary glass enclosure
- Convenience outlet provision
- Provision for split-type
- Provision for pipe sleeve at external wall for refrigerant
type
- Provision of FCU drain
- Provision of power circuit breaker at ACCU area |
KITCHEN
AREA
. Kitchen Base Cabinet only
. Laminated doors on melamine carcass with China granite
countertop and 100 mm high China granite splashboard |
OTHER
UNIT FEATURES
. MECHANICAL VENTILATION
- Provision of mechanical
exhaust / ventilation duct for kitchen and Toilet &
Bath
. CLOSET
- Bedroom closet provided
with laminated doors on melamine carcass |
UNIT
HEIGHT
Unit Floor to Floor Height : 3.00 m.
Unit Floor to Underside of Slab : 2.75 m.
Kitchen Ceiling : 2.40 m.
Toilet and Bath : 2.20 m. |
POWER
SUPPLY
Generator
Common areas : 100% power supply back-up
Residential unit : min. of 30% power supply back-up
CONCEALED TOILET PIPING
Advantages
. All plumbing pipework relevant to a particular
apartment are kept within that apartment.
. Vent piping will be drastically reduced.
. Eliminates occurrence of the following:
. Smell caused by tenant above.
. Drying of trap seal
. Leaks from exposed pipeworks.
. Maintenance will be confined within their own apartment,
eliminating the need to disturb unit tenant below.
. Considerable cost reduction to the following (due to possible
reduction of floor to floor height).
. Structural concrete and rebar. |
COMMUNICATION
. Provision for telephone lies
. Provision for Cable TV
MECHANICAL
Elevator : 2
passenger elevators, 1 passenger service elevator
Load Capacity : 900
kilos lift capacity (ave. 14-15 persons)
No. of Passengers : Transports average of 43 persons every
5 minutes
Speed : 2.5
sec. floor to floor with 30-32 sec. waiting time only
FIRE PROTECTION / ALARM
- Water sprinkler system
- Fire alarm and detection system |
